Table 229: Communities Output Field Values (continued)
DescriptionValue
1 byte. Currently this is only used if the route type is 5 or 7. Setting the least significant bit in
the field indicates that the route carries a type 2 metric.
options
(Used with VPNs) Identifies where the route came from.origin
1 byte, encoded as 1 or 2 for intra-area routes (depending on whether the route came from a
type 1 or a type 2 LSA); 3 for summary routes; 5 for external routes (area number must be0);
7 for NSSA routes; or 129 for sham link endpoint addresses.
ospf-route-type
Displays the area number, OSPF route type, and option of the route. This is configured using
the BGP extended community attribute 0x8000. The format is
area-number:ospf-route-type:options.
route-type-vendor
Displays the area number, OSPF route type, and option of the route. This is configured using
the BGP extended community attribute 0x0306. The format is
area-number:ospf-route-type:options.
rte-type
Defines which VPN the route participates in; target has the format 32-bit IP address:16-bit
number. For example, 10.19.0.0:100.
target
Incoming IANA codes with a value between 0x1 and 0x7fff. This code of the BGP extended
community attribute is accepted, but it is not recognized.
unknown IANA
Incoming IANA codes with a value above 0x8000. This code of the BGP extended community
attribute is accepted, but it is not recognized.
unknown OSPF vendor
community
Sample Output
show route table bgp.l2.vpn
user@host> show route table bgp.l2.vpn
bgp.l2vpn.0: 1 destinations, 1 routes (1 active, 0 holddown, 0 hidden)
+ = Active Route, - = Last Active, * = Both
192.168.24.1:1:4:1/96
*[BGP/170] 01:08:58, localpref 100, from 192.168.24.1
AS path: I
> to 10.0.16.2 via fe-0/0/1.0, label-switched-path am
show route table bgp.l3vpn.0
user@host> show route table bgp.l3vpn.0
bgp.l3vpn.0: 2 destinations, 2 routes (2 active, 0 holddown, 0 hidden)
+ = Active Route, - = Last Active, * = Both
10.255.71.15:100:10.255.71.17/32
*[BGP/170] 00:03:59, MED 1, localpref 100, from
10.255.71.15
AS path: I
> via so-2/1/0.0, Push 100020, Push 100011(top)
10.255.71.15:200:10.255.71.18/32
Copyright © 2017, Juniper Networks, Inc.3126
