Table 35: SNMP MIB Objects for get, get-next, and walk management
DescriptionObject
SNMP
MIB
Denotes the following PTP Servo states:
•
INITIALIZING
•
ACQUIRING
•
PHASE ALIGNED
•
FREERUN
•
HOLDOVER
•
FREQUENCY LOCKED
jnxPtpServoStatePTP MIB
Denotes the PTP Servo state string:
•
INITIALIZING
•
ACQUIRING (Master is elected and servo starts acquiring lock)
•
PHASE ALIGNED (Locked to Master)
•
FREERUN (no PTP source available)
•
HOLDOVER (Slave locked to PTP for more than 12 hours and then loses
all the PTP sources)
jnxPtpServoStateStr
Denotes the class of the PTP grandmaster clock.jnxPtpClass
Denotes the PTP grandmaster clock identifier.jnxPtpGmId
Denotes the SSM/ESMC quality level of the locked source in decimal format.jnxClksyncQualityCodeSyncE MIB
Denotes the SSM/ESMC quality level of the locked source in string formatjnxClksyncQualityCodeStr
Denotes the interface index of the locked source in decimal format.jnxClksyncIfIndex
Denotes the interface name of the locked source in string format.jnxClksyncIntfName
Displays the status of the GPS receiver.jnxGpsRecvStatusGPS MIB
NOTE:
•
The SNMP get and walk management are supported only for scalar objects.
•
For SyncE objects, the jnxClksyncQualityCode, jnxClksyncQualityCodeStr,
jnxClksyncIfIndex, and jnxClksyncIntfName objects displays only for locked
source.
You can use the show chassis synchronization extensive, show ptp lock-status detail, show
snmp mib get <MIB-timing-objects>, and show snmp mib walk jnxTimingNotfObjects show
commands for monitoring and troubleshooting purposes.
