Jan 24 11:06:36 2013 In lbl Update 299776
Jan 24 11:06:36 2013 loc intf up lt-1/2/0.600
user@PE2> show l2circuit connections extensive
Layer-2 Circuit Connections:
Legend for connection status (St)
EI -- encapsulation invalid NP -- interface h/w not present
MM -- mtu mismatch Dn -- down
EM -- encapsulation mismatch VC-Dn -- Virtual circuit Down
CM -- control-word mismatch Up -- operational
VM -- vlan id mismatch CF -- Call admission control failure
OL -- no outgoing label IB -- TDM incompatible bitrate
NC -- intf encaps not CCC/TCC TM -- TDM misconfiguration
BK -- Backup Connection ST -- Standby Connection
CB -- rcvd cell-bundle size bad SP -- Static Pseudowire
LD -- local site signaled down RS -- remote site standby
RD -- remote site signaled down HS -- Hot-standby Connection
XX -- unknown
Legend for interface status
Up -- operational
Dn -- down
Neighbor: 192.168.0.100
Interface Type St Time last up # Up trans
lt-1/2/0.600(vc 2) rmt Up Jan 24 10:55:31 2013 1
Remote PE: 192.168.0.100, Negotiated control-word: Yes (Null)
Incoming label: 299776, Outgoing label: 299792
Negotiated PW status TLV: Yes
local PW status code: 0x00000000, Neighbor PW status code: 0x00000020
Local interface: lt-1/2/0.600, Status: Up, Encapsulation: VLAN
Connection History:
Jan 24 10:55:31 2013 status update timer
Jan 24 10:55:31 2013 PE route changed
Jan 24 10:55:31 2013 Out lbl Update 299792
Jan 24 10:55:31 2013 In lbl Update 299776
Jan 24 10:55:31 2013 loc intf up lt-1/2/0.600
Meaning From the perspective of Device PE1 and Device PE2, a single Layer 2 circuit is established
toward access routers, so there is no standby device information in the CLI output of the
show l2circuit connections command. Note that no timing and flapping information is
provided for the VC acting as the hot-standby. Junos OS allows only these counters to
be tracked for the active VC.
Checking the Policy Conditions
Purpose On the PE devices, verify the state of the different conditions defined as part of the Layer3
VPN's egress policy, where 10.41.0.0/24 corresponds to the logical tunnel (y) subnet.
Action From operational mode, enter the show policy conditions detail command.
user@PE1> show policy conditions detail
Copyright © 2017, Juniper Networks, Inc.648
ACX Series Universal Access Router Configuration Guide
