pce PCE2 {
destination-ipv4-address 192.168.70.65;
destination-port 4189;
pce-group PCEGROUP;
}
If you are done configuring the device, enter commit from configuration mode.
Verification
Confirm that the configuration is working properly.
•
Verifying PCC Status on page 728
•
Verifying PCE1 Status on page 729
•
Verifying the PCE-Initiated LSP Status When the LSP Is Externally
Provisioned on page 731
Verifying PCC Status
Purpose Verify the PCEP session status and LSP summary between the PCC and the connected
PCEs.
Action From operational mode, run the show path-computation-client status command.
user@PCC# show path-computation-client status
Session Type Provisioning Status
PCE1 Stateful Active On Up
PCE2 Stateful Active On Up
LSP Summary
Total number of LSPs : 1
Static LSPs : 0
Externally controlled LSPs : 0
Externally provisioned LSPs : 1/16000 (current/limit)
Orphaned LSPs : 0
PCE1 (main)
Delegated : 1
Externally provisioned : 1
PCE2
Delegated : 0
Externally provisioned : 0
Meaning The output displays the status of the PCEP session between the active stateful PCEs
and the PCC. It also displays information about the different types of LSPs on the PCC,
and the number of LSPs provisioned by the connected PCEs and delegated to them.
PCE1 is the main active PCE and has one PCE-initiated LSP that has been automatically
delegated to it by the PCC.
Copyright © 2017, Juniper Networks, Inc.728
ACX Series Universal Access Router Configuration Guide
