Chapter
３
Native Device Message List
3-10
3.6 Marker Settings
Device messages for setting the marker are shown in Table 3.6-1.
Table 3.6-1 Marker setting messages
Function Command Query Response Remarks
Marker Mode
MKR mode_com,marker MKR? marker mode_res
mode_com
: Marker mode
marker
: Marker type
Zone Marker Position
MKZ point,marker MKZ? marker point
point
: Number of displayed points
from left edge
marker
: Marker type
Zone Marker Frequency (Time)
MKZF freq,marker MKZF? marker freq
marker
: Marker type
Zone Marker Frequency (Time)
CALC:MARK:X:DELT
freq,marker
CALC:MARK:X:DELT? marker freq
marker
: Marker type
CALC:MARK:X:DELT
time,marker
CALC:MARK:X:DELT? marker time
Zone Marker Width
MKW width,marker MKW? marker width
width
: Specifies width
= 0 | 1 | 2 | 5 | 6 | 7
marker
: Marker type
Zone Marker Width (by Point)
MZW point,marker MZW? marker point
point
: Number of displayed points
marker
: Marker type
Zone Marker Width (by
Frequency)
MZWF freq,marker MZWF? marker freq
freq
: Frequency width
marker
: Marker type
Marker Trace
MKTRACE trace,marker MKTRACE? marker_query trace
trace
: Trace type
marker
: Marker type
marker_query
: Marker type
