Anritsu MS2840A - 2.13 Spectrum Emission Mask

Chapter 2 SCPI Device Message Details
2-574
2.13 Spectrum Emission Mask
Table 2.13-1 lists device messages for Spectrum Emission Mask
measurement.
Table 2.13-1 Device messages for Spectrum Emission Mask measurement
Function Device Message
Measure Spectrum
Emission Mask
[:SENSe]:SEMask[:STATe] ON|OFF|1|0
[:SENSe]:SEMask[:STATe]?
Spectrum Emission
Mask Limit Side
[:SENSe]:SEMask:OFFSet[1]:SIDE BOTH|POSitive|NEGative
[:SENSe]:SEMask:OFFSet[1]:SIDE?
Spectrum Emission
Mask Reference Type
[:SENSe]:SEMask:TYPE TPRef|PKRef|FIX
[:SENSe]:SEMask:TYPE?
:CALCulate:SEMask:TYPE TPRef|PKRef|FIX
:CALCulate:SEMask:TYPE?
Spectrum Emission
Mask Reference
Power
[:SENSe]:SEMask:CARRier[:POWer] <ampl>
[:SENSe]:SEMask:CARRier[:POWer]?
:CALCulate:SEMask:CARRier[:POWer] <ampl>
:CALCulate:SEMask:CARRier[:POWer]?
Spectrum Emission
Mask Integrate
Bandwidth
[:SENSe]:SEMask:BANDwidth[1]:CHANnel|:INTegration <bandwidth>
[:SENSe]:SEMask:BANDwidth[1]:CHANnel|INTegration?
Spectrum Emission
Mask Attenuator
[:SENSe]:SEMask:ATTenuation <rel_ampl>|AUTO
[:SENSe]:SEMask:ATTenuation?
Spectrum Emission
Mask Offset
Attenuator
[:SENSe]:SEMask:OFFSet[1]:LIST:ATTenuation <rel_ampl_1>|AUTO
[,<rel_ampl_2>|AUTO [,<rel_ampl_3>|AUTO [,<rel_ampl_4>|AUTO
[,<rel_ampl_5>|AUTO [,<rel_ampl_6>|AUTO [,<rel_ampl_7>|AUTO
[,<rel_ampl_8>|AUTO [,<rel_ampl_9>|AUTO [,<rel_ampl_10>|AUTO
[,<rel_ampl_11>|AUTO [,<rel_ampl_12>|AUTO]]]]]]]]]]]
[:SENSe]:SEMask:OFFSet[1]:LIST:ATTenuation?
Spectrum Emission
Mask Resolution
Bandwidth
[:SENSe]:SEMask:BANDwidth[1][:RESolution] <bandwidth>
[:SENSe]:SEMask:BANDwidth[1][:RESolution]?
Spectrum Emission
Mask Resolution
Bandwidth
Auto/Manual
[:SENSe]:SEMask:BANDwidth[1][:RESolution]:AUTO ON|OFF|1|0
[:SENSe]:SEMask:BANDwidth[1][:RESolution]:AUTO?
