2.6 Trace
2-183
2
SCPI Device Message Details
2.6 Trace
Table 2.6-1 lists device messages for trace.
Note:
All commands can be also executed even when
LIMit
is described
instead of
LLINe
.
Table 2.6-1 Device message for trace
Function Device Message
Active Trace
:TRACe:ACTive A|B|C|D|E|F
:TRACe:ACTive?
Trace Write Mode
:TRACe[1]|2|3|4|5|6:TYPE WRITe|VIEW|BLANk
:TRACe[1]|2|3|4|5|6:TYPE?
Storage Mode
:TRACe[1]|2|3|4|5|6:STORage:MODE
OFF|MAXHold|AVERage|MINHold|LAVerage
:TRACe[1]|2|3|4|5|6:STORage:MODE?
Average Count
[:SENSe]:AVERage:COUNt <integer>
[:SENSe]:AVERage:COUNt?
Sweep Count Query
:TRACe:SWEep:COUNt?
Limit Edit
:CALCulate:LLINe[1]|2|3|4|5|6:DATA
<x-axis_1>,<ampl_1>,<connected_1>[,<x-axis_2>,<ampl_2>,<connected_2>
],,,[,<x-axis_n>,<ampl_n>,<connected_n>]
:CALCulate:LLINe[1]|2|3|4|5|6:DATA?
Limit Type
:CALCulate:LLINe[1]|2|3|4|5|6:TYPE UPPer|LOWer
:CALCulate:LLINe[1]|2|3|4|5|6:TYPE?
Limit Display
:CALCulate:LLINe[1]|2|3|4|5|6:DISPlay OFF|ON|0|1
:CALCulate:LLINe[1]|2|3|4|5|6:DISPlay?
Limit Test
:CALCulate:LLINe[1]|2|3|4|5|6:STATe OFF|ON|0|1
:CALCulate:LLINe[1]|2|3|4|5|6:STATe?
Limit Test Result
:CALCulate:LLINe[1]|2|3|4|5|6:FAIL?
Margin
:CALCulate:LLINe[1]|2|3|4|5|6:MARGin:STATe OFF|ON|0|1
:CALCulate:LLINe[1]|2|3|4|5|6:MARGin:STATe?
Margin Value
:CALCulate:LLINe[1]|2|3|4|5|6:MARGin <ampl_rel>
:CALCulate:LLINe[1]|2|3|4|5|6:MARGin?
Delete Limit
:CALCulate:LLINe[1]|2|3|4|5|6:DELete
Delete All Limits
:CALCulate:LLINe:ALL:DELete
Limits Line Type
(Amplitude)
:CALCulate:LLINe[1]|2|3|4|5|6:CMODe:AMPLitude FIXed|
ABSolute|RELative
:CALCulate:LLINe:CMODe:AMPLitude?
Limits Line Type
(Frequency)
:CALCulate:LLINe[1]|2|3|4|5|6:CMODe:FREQuency
FIXed|ABSolute|RELative
:CALCulate:LLINe[1]|2|3|4|5|6:CMODe:FREQuency?
