3.8 Trace Settings
Table 3.8-1 lists device messages for setting trace.
Table 3.8-1 Trace setting messages
Function Command Query Response Remarks
Active Trace
MKTRACE trace
MKTRACE?
trace
trace
: Trace
=
TRA | TRB | TRC| TRD | TRE |
TRF
ACTIVETRACE trace ACTIVETRACE?
Trace Write Mode
WRITEMODE mode WRITEMODE? mode
mode
: Write mode
Storage Mode (Active Trace)
STORAGEMODE mode STORAGEMODE? mode
mode
: Storage mode
= OFF | MAX | AVG | MIN | LINAVG
Average Mode (Active Trace)
VAVG on_off --- ---
Storage Mode (Trace A)
AMD mode
AMD?
mode
mode
: Storage mode
Storage Mode (Trace B)
BMD mode BMD? mode
mode
: Storage mode
Storage Mode (Trace C)
CMD mode
CMD?
mode
mode
: Storage mode
Storage Mode (Trace D)
DMD mode DMD? mode
mode
: Storage mode
Storage Mode (Trace E)
EMD mode
EMD?
mode
mode
: Storage mode
Storage Mode (Trace F)
FMD mode FMD? mode
mode
: Storage mode
Storage Count
STORAGECOUNT count
STORAGECOUNT?
count
count
: Count
VAVG count VAVG?
HOLDPAUSE count
HOLDPAUSE?
Sweep Count
--- SWEEPCOUNT? count
count
: Sweep count
