Chapter 2 SCPI Device Message Detail
2-732
[:SENSe]:SPURious[:RANGe][:LIST]:SEGMent:STATe
ON|OFF|1|0,ON|OFF|1|0,ON|OFF|1|0,ON|OFF|1|0,ON|OFF|1|0,
ON|OFF|1|0,ON|OFF|1|0,ON|OFF|1|0,ON|OFF|1|0,ON|OFF|1|0,
ON|OFF|1|0,ON|OFF|1|0,ON|OFF|1|0,ON|OFF|1|0,ON|OFF|1|0,
ON|OFF|1|0,ON|OFF|1|0,ON|OFF|1|0,ON|OFF|1|0,ON|OFF|1|0
Segment On/Off
Function
This command sets the segment to On/Off.
Command
[:SENSe]:SPURious[:RANGe][:LIST]:SEGMent:STATe <switch_n>
Parameter
<switch_n>
Segment n On/Off
ON|1
Segment is set to On.
OFF|0
Segment is set to Off.
Default
[MS269xA]
Segment 1 to 8 On
Segment 9 to 15 On (Off for MS2690A)
Segment 16 to 20 Off
[MS2830A]
Segment 1 to 6 On
Segment 7 to 8 On (Off for Option 040)
Segment 9 to 15 On (Off for Option 040/041)
Segment 16 to 18 On (Off for Option 040/041/043)
Segment 19 to 20 On (Off for Option 040/041/043/044)
[MS2840A]
Segment 1 to 6 On
Segment 7 to 8 On (Off for Option 040)
Segment 9 to 18 On (Off for Option 040/041)
Segment 19 to 20 On (Off for Option 040/041/044)
Details
This command cannot set all the segments to Off at the same time.
Example of Use
To set the segment to On/Off.
SPUR:SEGM:STAT
ON,ON,OFF,ON,ON,OFF,ON,ON,OFF,ON,ON,OFF,ON,ON,OFF,ON,ON,
OFF,ON,ON
