2.15 Setting the TOI Measurement Functions
2-821
2
SCPI Device Message Details
2.15 Setting the TOI Measurement Functions
Table 2.15-1 lists device messages for setting the TOI measurement
functions.
Table 2.15-1 Device messages for setting the TOI measurement functions
Function Device Message
Measure TOI
[:SENSe]:TOI[:STATe] ON|OFF|1|0
[:SENSe]:TOI[:STATe]?
:CALCulate:TOI[:STATe] ON|OFF|1|0
:CALCulate:TOI[:STATe]?
TOI Frequency Auto
Tune
[:SENSe]:TOI:FREQuency:TUNE:IMMediate
TOI Lower
Tone Frequency
[:SENSe]:TOI:FREQuency:BASE:LOWer <freq>
[:SENSe]:TOI:FREQuency:BASE:LOWer?
:CALCulate:TOI:FREQuency:BASE:LOWer <freq>
:CALCulate:TOI:FREQuency:BASE:LOWer?
TOI Upper
Tone Frequency
[:SENSe]:TOI:FREQuency:BASE:UPPer <freq>
[:SENSe]:TOI:FREQuency:BASE:UPPer?
:CALCulate:TOI:FREQuency:BASE:UPPer <freq>
:CALCulate:TOI:FREQuency:BASE:UPPer?
TOI Tone
Frequency
Auto/Manual
[:SENSe]:TOI:FREQuency:BASE[:LOWer[:UPPer]]:AUTO ON|OFF|1|0
[:SENSe]:TOI:FREQuency:BASE[:LOWer[:UPPer]]:AUTO?
:CALCulate:TOI:FREQuency:BASE[:LOWer[:UPPer]]:AUTO ON|OFF|1|0
:CALCulate:TOI:FREQuency:BASE[:LOWer[:UPPer]]:AUTO?
TOI Zero Span
Measurement
On/Off
[:SENSe]:TOI:ZSPan[:STATe] ON|OFF|1|0
[:SENSe]:TOI:ZSPan[:STATe]?
TOI Zero Span
Measurement
Resolution
Bandwidth
[:SENSe]:TOI:ZSPan:BANDwidth|BWIDth[:RESolution] <freq>
[:SENSe]:TOI:ZSPan:BANDwidth|BWIDth[:RESolution]?
TOI Zero Span
Measurement
Resolution
Bandwidth
Auto/Manual
[:SENSe]:TOI:ZSPan:BANDwidth|BWIDth[:RESolution]:AUTO ON|OFF|1|0
[:SENSe]:TOI:ZSPan:BANDwidth|BWIDth[:RESolution]:AUTO?
TOI Zero Span
Sweep Time
[:SENSe]:TOI:ZSPan:SWEep:TIME <time>
[:SENSe]:TOI:ZSPan:SWEep:TIME?
TOI Zero Span
Measurement Sweep
Time Auto/Manual
[:SENSe]:TOI:ZSPan:SWEep:TIME:AUTO ON|OFF|1|0
[:SENSe]:TOI:ZSPan:SWEep:TIME:AUTO?
