2.12 OBW
2-527
2
SCPI Device Message Details
2.12 OBW
Table 2.12-1 lists device messages for occupied bandwidth measurement.
Table 2.12-1 Device Messages for Occupied Bandwidth measurement
Function Device Message
Measure Occupied
Bandwidth
[:SENSe]:OBWidth[:STATe] ON|OFF|1|0
[:SENSe]:OBWidth[:STATe]?
:CALCulate:OBWidth[:STATe] ON|OFF|1|0
:CALCulate:OBWidth[:STATe]?
OBW Method
[:SENSe]:OBWidth:METHod NPERcent|XDB
[:SENSe]:OBWidth:METHod?
:CALCulate:OBWidth:METHod NPERcent|XDB
:CALCulate:OBWidth:METHod?
OBW N% Ratio
[:SENSe]:OBWidth:PERCent <real>
[:SENSe]:OBWidth:PERCent?
:CALCulate:OBWidth:PERCent <real>
:CALCulate:OBWidth:PERCent?
OBW X dB Value
[:SENSe]:OBWidth:XDB <rel_ampl>
[:SENSe]:OBWidth:XDB?
:CALCulate:OBWidth:XDB <rel_ampl>
:CALCulate:OBWidth:XDB?
Occupied Bandwidth
Configure
:CONFigure:OBWidth
Occupied Bandwidth
Initiate
:INITiate:OBWidth
Occupied Bandwidth
Fetch
:FETCh:OBWidth[n]?
:FETCh:OBWidth:FERRor?
Occupied Bandwidth
Read
:READ:OBWidth[n]?
:READ:OBWidth:FERRor?
Occupied Bandwidth
Measure
:MEASure:OBWidth[n]?
:MEASure:OBWidth:FERRor?
All Marker Off
:CALCulate:OBWidth:MARKer:AOFF
Peak Search
:CALCulate:OBWidth:MARKer[1]|2|3|4|5|6|7|8|9|10:MAXimum
Power Peak Search
:CALCulate:OBWidth:MARKer[1]|2|3|4|5|6|7|8|9|10:MAXimum:POWer
Minimum Search
:CALCulate:OBWidth:MARKer[1]|2|3|4|5|6|7|8|9|10:MINimum
