Anritsu MS2840A - Page 538

Chapter 2 SCPI Device Message Details
2-528
Table 2.12-1 Device Messages for Occupied Bandwidth measurement (Cont’d)
Function Device Message
Marker Mode
:CALCulate:OBWidth:MARKer[1]|2|3|4|5|6|7|8|9|10:MODE
NORMal|POSition|DELTa|FIXed|OFF
:CALCulate:OBWidth:MARKer[1]|2|3|4|5|6|7|8|9|10:MODE?
Zone Marker
Frequency (Time)
:CALCulate:OBWidth:MARKer[1]|2|3|4|5|6|7|8|9|10:X <freq>|<time>
:CALCulate:OBWidth:MARKer[1]|2|3|4|5|6|7|8|9|10:X?
Zone Marker
Position
:CALCulate:OBWidth:MARKer[1]|2|3|4|5|6|7|8|9|10:X:POSition
<integer>
:CALCulate:OBWidth:MARKer[1]|2|3|4|5|6|7|8|9|10:X:POSition?
Marker Level
:CALCulate:OBWidth:MARKer[1]|2|3|4|5|6|7|8|9|10:Y?
Title Entry
:DISPlay:OBWidth:ANNotation:TITLe:DATA <string>
:DISPlay:OBWidth:ANNotation:TITLe:DATA?
Log Scale Range
:DISPlay:OBWidth:VIEW[1]:WINDow[1]:TRACe:Y[:SCALe]:PDIVision
<rel_ampl>
:DISPlay:OBWidth:VIEW[1]:WINDow[1]:TRACe:Y[:SCALe]:PDIVision?
Reference Level
:DISPlay:OBWidth:VIEW[1]:WINDow[1]:TRACe:Y[:SCALe]:RLEVel <real>
:DISPlay:OBWidth:VIEW[1]:WINDow[1]:TRACe:Y[:SCALe]:RLEVel?
Trigger Source
:TRIGger:OBWidth[:SEQuence]:SOURce
EXTernal[1]|IMMediate|WIF|RFBurst|VIDeo|SG|BBIF|FRAMe
:TRIGger:OBWidth[:SEQuence]:SOURce?
Average Count
[:SENSe]:OBWidth:AVERage:COUNt <integer>
[:SENSe]:OBWidth:AVERage:COUNt?
Storage Mode
[:SENSe]:OBWidth:AVERage[:STATe] ON|OFF|1|0
[:SENSe]:OBWidth:AVERage[:STATe]?
Resolution
Bandwidth
[:SENSe]:OBWidth:BANDwidth[:RESolution] <freq>
[:SENSe]:OBWidth:BANDwidth[:RESolution]?
:CALCulate:OBWidth:BANDwidth[:RESolution] <freq>
:CALCulate:OBWidth:BANDwidth[:RESolution]?
Resolution
Bandwidth
Auto/Manual
[:SENSe]:OBWidth:BANDwidth[:RESolution]:AUTO ON|OFF|1|0
[:SENSe]:OBWidth:BANDwidth[:RESolution]:AUTO?
:CALCulate:OBWidth:BANDwidth[:RESolution]:AUTO ON|OFF|1|0
:CALCulate:OBWidth:BANDwidth[:RESolution]:AUTO?
Resolution
Bandwidth
Normal/CISPR
[:SENSe]:OBWidth:BANDwidth[:RESolution]:MODE NORMal|CISPr
[:SENSe]:OBWidth:BANDwidth[:RESolution]:MODE?
:CALCulate:OBWidth:BANDwidth[:RESolution]:MODE NORMal|CISPr
:CALCulate:OBWidth:BANDwidth[:RESolution]:MODE?
