Anritsu MS2840A - [:SENSe]:TOI:FREQuency:BASE:UPPer <freq>

Chapter 2 SCPI Device Message Detail
2-828
[:SENSe]:TOI:FREQuency:BASE:UPPer <freq>
TOI Upper Tone Frequency
Function
This command sets the upper tone frequency for the TOI measurement.
Command
[:SENSe]:TOI:FREQuency:BASE:UPPer <freq>
Parameter
<freq>
Upper tone frequency for the TOI measurement
Range
[MS269xA]
–100 MHz to 6.05 GHz (MS2690A)
–100 MHz to 13.6 GHz (MS2691A)
–100 MHz to 26.6 GHz (MS2692A)
[MS2830A]
–100 MHz to 3.7 GHz (Option 040)
–100 MHz to 6.1 GHz (Option 041)
–100 MHz to 13.6 GHz (Option 043)
–100 MHz to 26.6 GHz (Option 044)
–100 MHz to 43.1 GHz (Option 045)
[MS2840A]
–100 MHz to 3.7 GHz (Option 040)
–100 MHz to 6.1 GHz (Option 041)
–100 MHz to 26.6 GHz (Option 044)
–100 MHz to 44.6 GHz (Option 046)
Resolution 1 Hz
Suffix code HZ, KHZ, KZ, MHZ, MZ, GHZ, GZ
Hz is used when omitted.
Default
[MS269xA]
3.75 GHz (MS2690A)
8.4375 GHz (MS2691A)
16.5625 GHz (MS2692A)
[MS2830A]
1.875 GHz (Option 040)
3.75 GHz (Option 041)
8.4375 GHz (Option 043)
16.5625 GHz (Option 044)
26.875 GHz (Option 045)
[MS2840A]
1.875 GHz (Option 040)
3.75 GHz (Option 041)
16.5625 GHz (Option 044)
26.875 GHz (Option 046)
Example of Use
To set the upper tone frequency to 2 GHz.
TOI:FREQ:BASE:UPP 2GHZ
