3.10.4 Channel power measurement function settings
Device messages for channel power measurement settings are shown in Table 3.10.4-1.
Table 3.10.4-1 Channel power measurement function setting messages
Function Command Query Response Remarks
Measure Channel Power
MEAS CHPWR
MEAS?
CHPWR
MEAS OFF MEAS? OFF
Channel Power Channel Center
Frequency
CHPWRCENTER freq CHPWRCENTER? freq
Channel Power Channel
Bandwidth
CHPWRWIDTH freq CHPWRWIDTH? freq
Channel Power Filter Type
CHPWRFLTRTYP filter CHPWRFLTRTYP? filter
filter:
Filter type
= RECT | NYQUIST | ROOTNYQUIST
Channel Power Rolloff Factor
CHPWRROF ratio CHPWRROF? ratio
ratio:
Filter rolloff factor
Channel Power Measurement
Result Query
--- RES? power,density
power
: Total power of the channel
density
: Mean power spectral
density of the channel
