2.7 Sweep/Trigger/Gate
2-247
2
SCPI Device Message Details
2.7 Sweep/Trigger/Gate
Table 2.7-1 lists device messages for sweep/trigger/gate.
Table 2.7-1 Device messages for sweep/trigger/gate
Function Device Message
Continuous
Measurement
:INITiate:CONTinuous OFF|ON|0|1
:INITiate:CONTinuous?
:INITiate:MODE:CONTinuous
Single
Measurement
:INITiate:MODE:SINGle
Initiate
:INITiate[:IMMediate]
Single Sweep
:INITiate:SWP
:INITiate:SWP?
Sweep Time
[:SENSe]:SWEep:TIME <time>
[:SENSe]:SWEep:TIME?
Sweep Time
Auto/Manual
[:SENSe]:SWEep:TIME:AUTO OFF|ON|0|1
[:SENSe]:SWEep:TIME:AUTO?
Auto Sweep Time
Mode
[:SENSe]:SWEep:TIME:AUTO:MODE NORMal|FAST
[:SENSe]:SWEep:TIME:AUTO:MODE?
Trace Point
[:SENSe]:SWEep:POINts <integer>
[:SENSe]:SWEep:POINts?
Auto Sweep Type
Select Rules
[:SENSe]:SWEep[:TYPE][:AUTO]:RULes DRANge|SPEed|OSWeep|PSWeep|PFFT
[:SENSe]:SWEep[:TYPE][:AUTO]:RULes?
Sweep Type Select
Rules FFT Width
[:SENSe]:SWEep[:TYPE][:AUTO]:RULes:FFT:WIDTh <freq>
[:SENSe]:SWEep[:TYPE][:AUTO]:RULes:FFT:WIDTh?
Sweep Type Select
Rules Real FFT
Width
[:SENSe]:SWEep[:TYPE][:AUTO]:RULes:FFT:RWIDth?
Sweep Type Select
Rules Real Type
[:SENSe]:SWEep[:TYPE][:AUTO]:RULes:RTYPe?
Detection Mode
[:SENSe]:DETector[:FUNCtion]
NORMal|POSitive|SAMPle|NEGative|RMS|QPEak|CAVerage|CRMS
[:SENSe]:DETector[:FUNCtion]?
:CALCulate:DETector[:FUNCtion]
NORMal|POSitive|SAMPle|NEGative|RMS|QPEak|CAVerage|CRMS
:CALCulate:DETector[:FUNCtion]?
Trigger Switch
:TRIGger[:SEQuence][:STATe] ON|OFF|1|0
:TRIGger[:SEQuence][:STATe]?
Trigger Source
:TRIGger[:SEQuence]:SOURce
EXTernal[1]|IMMediate|WIF|RFBurst|VIDeo|SG|BBIF|FRAMe
:TRIGger[:SEQuence]:SOURce?
Log Scale Video
Trigger Level
:TRIGger[:SEQuence]:VIDeo:LEVel[:LOGarithmic] <level>
:TRIGger[:SEQuence]:VIDeo:LEVel[:LOGarithmic]?
Linear Scale Video
Trigger Level
:TRIGger[:SEQuence]:VIDeo:LEVel:LINear <level>
:TRIGger[:SEQuence]:VIDeo:LEVel:LINear?
