Chapter 2 SCPI Device Message Details
2-248
Table 2.7-1 Device messages for sweep/trigger/gate (Cont’d)
Function Device Message
Wide IF Trigger
Level
:TRIGger[:SEQuence]:WIF|:RFBurst:LEVel:ABSolute <level>
:TRIGger[:SEQuence]:WIF|:RFBurst:LEVel:ABSolute?
Trigger Slope
:TRIGger[:SEQuence]:EXTernal1:SLOPe POSitive|NEGative
:TRIGger[:SEQuence]:EXTernal1:SLOPe?
:TRIGger[:SEQuence]:WIF|:RFBurst:SLOPe POSitive|NEGative
:TRIGger[:SEQuence]:WIF|:RFBurst:SLOPe?
:TRIGger[:SEQuence]:VIDeo:SLOPe POSitive|NEGative
:TRIGger[:SEQuence]:VIDeo:SLOPe?
Trigger Delay
:TRIGger[:SEQuence]:EXTernal[1]:DELay <time>
:TRIGger[:SEQuence]:EXTernal[1]:DELay?
:TRIGger[:SEQuence]:WIF|:RFBurst:DELay <time>
:TRIGger[:SEQuence]:WIF|:RFBurst:DELay?
:TRIGger[:SEQuence]:VIDeo:DELay <time>
:TRIGger[:SEQuence]:VIDeo:DELay?
Trigger Hold
:TRIGger[:SEQuence]:HOLDoff <time>
:TRIGger[:SEQuence]:HOLDoff?
Trigger Hold
On/Off
:TRIGger[:SEQuence]:HOLDoff:STATe OFF|ON|0|1
:TRIGger[:SEQuence]:HOLDoff:STATe?
Frame Trigger
Period
:TRIGger[:SEQuence]:FRAMe:PERiod <time>
:TRIGger[:SEQuence]:FRAMe:PERiod?
Frame Sync Source
:TRIGger[:SEQuence]:FRAMe:SYNC EXTernal[1]|IMMediate|Off|WIF|RFBurst
:TRIGger[:SEQuence]:FRAMe:SYNC?
Frame Sync Offset
:TRIGger[:SEQuence]:FRAMe:OFFSet <time>
:TRIGger[:SEQuence]:FRAMe:OFFSet?
Gate Sweep
[:SENSe]:SWEep:EGATe[:STATe] ON|OFF|1|0
[:SENSe]:SWEep:EGATe[:STATe]?
Gate Source
[:SENSe]:SWEep:EGATe:SOURce
EXTernal[1]|IMMediate|WIF|RFBurst|SG|BBIF|FRAMe
[:SENSe]:SWEep:EGATe:SOURce?
Gate Level
[:SENSe]:SWEep:EGATe:WIF|:RFBurst:LEVel:ABSolute <ampl>
[:SENSe]:SWEep:EGATe:WIF|:RFBurst:LEVel:ABSolute?
Gate Slope
[:SENSe]:SWEep:EGATe:SLOPe POSitive|NEGative
[:SENSe]:SWEep:EGATe:SLOPe?
Gate Delay
[:SENSe]:SWEep:EGATe:DELay <time>
[:SENSe]:SWEep:EGATe:DELay?
Gate Length
[:SENSe]:SWEep:EGATe:LENGth <time>
[:SENSe]:SWEep:EGATe:LENGth?
Gate View
[:SENSe]:SWEep:EGATe:VIEW[:STATe] ON|OFF|1|0
[:SENSe]:SWEep:EGATe:VIEW[:STATe]?
Gate View
Sweep Time
[:SENSe]:SWEep:EGATe[:VIEW]:TIME <time>
[:SENSe]:SWEep:EGATe[:VIEW]:TIME?
