2.7 Sweep/Trigger/Gate
2-249
2
SCPI Device Message Details
Table 2.7-1 Device messages for sweep/trigger/gate (Cont’d)
Function Device Message
Gate View
Resolution
Bandwidth
Auto/Manual
[:SENSe]:SWEep:EGATe:VIEW:BANDwidth[:RESolution]:AUTO ON|OFF|1|0
[:SENSe]:SWEep:EGATe:VIEW:BANDwidth[:RESolution]:AUTO?
Gate View
Resolution
Bandwidth
[:SENSe]:SWEep:E
GATe:VIEW:BANDwidth[:RESolution] <freq>
[:SENSe]:SWEep:EGATe:VIEW:BANDwidth[:RESolution]?
Gate View
Video Bandwidth
Auto/Manual
[:SENSe]:SWEep:EGATe:VIEW:BANDwidth:VIDeo:AUTO ON|OFF|1|0
[:SENSe]:SWEep:EGATe:VIEW:BANDwidth:VIDeo:AUTO?
Gate View
Video Bandwidth
[:SENSe]:SWEep:EGATe:VIEW:BANDwidth:VIDeo <freq>
[:SENSe]:SWEep:EGATe:VIEW:BANDwidth:VIDeo?
Gate View
Detection Mode
[:SENSe]:SWEep:EGATe:VIEW:DETector[:FUNCtion]
NORMal|POSitive|SAMPle|NEGative|RMS
[:SENSe]:SWEep:EGATe:VIEW:DETector[:FUNCtion]?
Gate View
Trace Point
[:SENSe]:SWEep:EGATe:VIEW:POINts <integer>
[:SENSe]:SWEep:EGATe:VIEW:POINts?
Gate View
Frequency Mode
[:SENSe]:SWEep:EGATe:VIEW:FREQuency:AUTO ON|OFF|1|0
[:SENSe]:SWEep:EGATe:VIEW:FREQuency:AUTO?
Gate View
Frequency
[:SENSe]:SWEep:EGATe:VIEW:FREQuency <freq>
[:SENSe]:SWEep:EGATe:VIEW:FREQuency?
Gate Hold
[:SENSe]:SWEep:EGATe:HOLDoff <time>
[:SENSe]:SWEep:EGATe:HOLDoff?
Gate Hold On/Off
[:SENSe]:SWEep:EGATe:HOLDoff:STATe OFF|ON|0|1
[:SENSe]:SWEep:EGATe:HOLDoff:STATe?
Restart Sweep
:INITiate:RESTart
Stop Sweep
:ABORt
