Anritsu MS2840A - 2.21 Setting External Mixer

Chapter 2 SCPI Device Message Detail
2-986
2.21 Setting External Mixer
Table 2.21-1 lists the device messages related to External Mixer settings.
Table 2.21-1 Device messages for setting External Mixer
Function
Device message
External Mixer Mode
[:SENSe]:MIXer[:STATe] ON|OFF|1|0
[:SENSe]:MIXer[:STATe]?
External Mixer Band
[:SENSe]:MIXer[:HARMonic]:BAND VHP|EHP|A|Q|U|V|E|W|F|D|G|Y|J
[:SENSe]:MIXer[:HARMonic]:BAND?
External Mixer Bias
[:SENSe]:MIXer:BIAS <bias>
[:SENSe]:MIXer:BIAS?
External Mixer Cable
Loss Value
[:SENSe]:MIXer:CABLe:LOSS <power>
[:SENSe]:MIXer:CABLe:LOSS?
External Mixer
Conversion Loss Mode
[:SENSe]:MIXer:LOSS:MODE FIXed|TABLe
[:SENSe]:MIXer:LOSS:MODE?
External Mixer
Conversion Loss Fixed
Value
[:SENSe]:MIXer:LOSS[:FIXed] <power>
[:SENSe]:MIXer:LOSS[:FIXed]?
External Mixer
Conversion Loss Table
[:SENSe]:MIXer:LOSS:TABLe
External Mixer
Conversion Loss Table
Serial Number Query
[:SENSe]:MIXer:LOSS:TABLe:SERial?
PS function (Center
Frequency)
[:SENSe]:MIXer:PS[:CENTer] ON|OFF|1|0
[:SENSe]:MIXer:PS[:CENTer]?
Signal Identifier
[:SENSe]:MIXer:SIGNal ON|OFF|1|0
[:SENSe]:MIXer:SIGNal?
Signal Identifier Mode
[:SENSe]:MIXer:SIGNal:MODE ISHift|ISUPpress
[:SENSe]:MIXer:SIGNal:MODE?
External Mixer
Calibration
[:SENSe]:MIXer:CALibration
