Chapter 2 SCPI Device Message Details
2-184
Table 2.6-1 Device message for trace (Cont’d)
Function Device Message
Save Wave Data
:MMEMory:STORe:TRACe
TRACe1|TRACe2|TRACe3|TRACe4|TRACe5|TRACe6|ALL[,<filename>[,<device>]]
Save Correction Data
:MMEMory:STORe:TRACe:CORRection [<filename>[,<device>]]
Query Trace Data
:TRACe[:DATA]? TRACe1|TRACe2|TRACe3|TRACe4|TRACe5|TRACe6|GVIew
Query Negative
Trace Data
:TRACe[:DATA]:NEGative?
TRACe1|TRACe2|TRACe3|TRACe4|TRACe5|TRACe6|GVIew
Query Trace Data
Spectrum Emission
Mask
:TRACe[:DATA]:SEMask?
REFerence|LOWer1|LOWer2|LOWer3|LOWer4|LOWer5|LOWer6|UPPer1|UPPer2|UP
Per3|UPPer4|UPPer5|UPPer6|ALL
Query Negative Trace
Data Spectrum
Emission Mask
:TRACe[:DATA]:SEMask:NEGative?
REFerence|LOWer1|LOWer2|LOWer3|LOWer4|LOWer5|LOWer6|UPPer1|UPPer2|UP
Per3|UPPer4|UPPer5|UPPer6|ALL
Binary Data Byte
Order
:FORMat:BORDer NORMal|SWAPped
:FORMat:BORDer?
Numeric Data Format
:FORMat[:DATA] ASCii|REAL|INTeger[,<length>]
:FORMat[:DATA]?
Test Trace
:CALCulate:LLINe[1]|2|3|4|5|6:TRACe <Trace>
:CALCulate:LLINe[1]|2|3|4|5|6:TRACe?
Previous Pt Level
Offset
:CALCulate:LLINe[1]|2|3|4|5|6:POINt:LEVel:OFFSet
<ampl_rel>[,<ampl_rel>],,,[,<ampl_rel>]
:CALCulate:LLINe[1]|2|3|4|5|6:POINt:LEVel:OFFSet?
Mirror Limit
:CALCulate:LLINe[1]|2|3|4|5|6:MIRRor ON|OFF|1|0
:CALCulate:LLINe[1]|2|3|4|5|6:MIRRor?
Create Envelope
:CALCulate:LLINe[1]|2|3|4|5|6:ENVelope:CREate
Update Envelope
:CALCulate:LLINe[1]|2|3|4|5|6:ENVelope:UPDate:Y
Envelope Points
:CALCulate:LLINe[1]|2|3|4|5|6:ENVelope:POINt <number>
:CALCulate:LLINe[1]|2|3|4|5|6:ENVelope:POINt?
Envelope Offset
:CALCulate:LLINe[1]|2|3|4|5|6:ENVelope[:LEVel]:OFFSet <amplitude>
:CALCulate:LLINe[1]|2|3|4|5|6:ENVelope[:LEVel]:OFFSet?
Envelope Shape
:CALCulate:LLINe[1]|2|3|4|5|6:ENVelope:SHAPe SQUare|SLOPe
:CALCulate:LLINe[1]|2|3|4|5|6:ENVelope:SHAPe?
Save Limit
:MMEMory:STORe:LLINe[1]|2|3|4|5|6:[<filename>[,<device>]]
Recall Limit Data file
:MMEMory:LOAD:LLINe[1]|2|3|4|5|6 <filename>[,<device>]
Delete Limit Data File
:MMEMory:DELete:LLINe <filename>[,<device>]
Delete All Limit Data
Files
:MMEMory:DELete:LLINe:ALL [<device>]
Delete Waveform Data
File
:MMEMory:DELete:WAVEform <foldername>[,<device>]
Delete All Waveform
Data Files
:MMEMory:DELete:WAVEform:ALL [<device>]
