Chapter 2 SCPI Device Message Detail
2-740
044)
[MS2840A]
Segment 1 150 kHz
Segment 2 30 MHz
Segment 3 1 GHz
Segment 4 2 GHz
Segment 5 3 GHz
Segment 6 4 GHz (3.6 GHz for Option 040)
Segment 7 5 GHz (3.6 GHz for Option 040)
Segment 8 6 GHz (3.6 GHz for Option 040)
Segment 9 7 GHz
(3.6 GHz for Option 040 and 6 GHz for Option 041)
Segment 10 8 GHz
(3.6 GHz for Option 040 and 6 GHz for Option 041)
Segment 11 9 GHz
(3.6 GHz for Option 040 and 6 GHz for Option 041)
Segment 12 10 GHz
(3.6 GHz for Option 040 and 6 GHz for Option 041)
Segment 13 11 GHz
(3.6 GHz for Option 040 and 6 GHz for Option 041)
Segment 14 14 GHz
(3.6 GHz for Option 040 and 6 GHz for Option 041)
Segment 16 18 GHz
(3.6 GHz for Option 040 and 6 GHz for Option 041)
Segment 17 24 GHz
(3.6 GHz for Option 040 and 6 GHz for Option 041)
Segment 18 32 GHz
(3.6 GHz for Option 040, 6 GHz for Option 041, and
26.5 GHz for Option 044)
Segment 19 42 GHz
(3.6 GHz for Option 040, 6 GHz for Option 041, and
26.5 GHz for Option 044)
Segment 20 44.5 GHz
(3.6 GHz for Option 040, 6 GHz for Option 041, and
26.5 GHz for Option 044)
Example of Use
To set the stop frequency of each segment.
SPUR:FREQ:STOP
150kHz,40MHz,1.1GHz,12.5GHz,12.5GHz,12.5GHz,12.5GHz,12.5
GHz,12.5GHz,12.5GHz,12.5GHz,12.5GHz,12.5GHz,12.5GHz,12.5
GHz,12.5GHz,12.5GHz,12.5GHz,12.5GHz,12.5GHz
