2.17 Configuring Batch Measurement Settings
2-869
2
SCPI Device Message Details
Table 2.17-5 Parameter List Settings (OBW Measurement) (Cont’d)
Parameter Attribute Name Setting Attribute Value Setting
Trigger Switch
“Trigger Switch”
“
Off
”: Off
“
On
”: On
Trigger Source
“Trigger Source”
“
Video
”: Video
“
External
”: External
“
SG Marker
”: SG Marker
“
Wide IF Video
”:
Wide IF Video
“
BBIF
”: BBIF
Trigger Slope
“Trigger Slope”
“
Rise
”: Rise
“
Fall
”: Fall
Trigger Level (Video)
“Trigger Level(Video)Log”
Value is described
in dBm units.
Trigger Level (Wide IF Video)
“Trigger Level(Wide)”
Value is described
in dBm units.
Gate Sweep
“Gate Sweep”
“
Off
”: Off
“
On
”: On
Gate Source
“Gate Source”
“
External
”: External
“
SG Marker
”: SG Marker
“
Wide IF Video
”:
Wide IF Video
“
BBIF
”: BBIF
Gate Delay
“Gate Delay”
Value is described
in ns units.
Gate Length
“Gate Length”
Value is described
in ns units.
Gate Level (Wide IF Video)
“Gate Level(Wide)”
Value is described
in dBm units.
Gate Slope
“Gate Slope”
“
Rise
”: Rise
“
Fall
”: Fall
Pre-amp
“Pre-amp”
“
Off
”: Off
“
On
”: On
VBW Mode
“VBW Mode”
“
Power
”: Power
“
Video
”: Video
OBW Method
“OBW Method”
“
N%
”: N%
“
XdB
”: XdB
OBW N% Ratio
“OBW N Ratio”
Value is described
in 0.01 % units.
OBW XdB Value
“OBW XdB Value”
Value is described
in 0.01 dB units.
Auto Sweep Time Select
“Auto Sweep Time Select”
“
Normal
”: Normal
“
Fast
”: Fast
