Chapter 2 SCPI Device Message Detail
2-932
<device>
Drive name
A,B,D,E,F,...
D drive is used when omitted.
<lower_offset_n_rel>
Relative power of lower Offset-n
<upper_offset_n_rel>
Relative power of upper Offset-n
No suffix code, dB unit, 0.001 dB resolution
–999.0 is returned when there is an error and no
measurement is performed.
<ref_carrier_a>
Power of reference carrier
<lower_offset_n_abs>
Absolute power of lower Offset-n
<upper_offset_n_abs>
Absolute power of upper Offset-n
No suffix code, Log Scale Unit (dBm unit for V
output and µW unit for W output)
–999.0 is returned when there is an error and no
measurement is performed.
<spa_n_result>
Peak search result (power) after measurement
with zero span with SPA[n] parameter
No suffix code, Log Scale Unit unit
(mV unit for V output and µW unit for W output)
–999.0 is returned when there is an error and no
measurement is performed.
Details
Transmit intermodulation measurement is executed and the result is
output based on the specified parameter list file.
Place the parameter list files in the following folder on the specified
drive.
<device>:\Anritsu Corporation\Signal Analyzer\User Data\Batch
If the parameter list file has been changed, the changes must be applied
with the
:MMEMory:RELoad:BATCh
command.
(cf.
:MMEMory:RELoad:BATCh
)
Example of Use
To execute Transmit intermodulation measurement using the
MyParam.xls parameter list file.
MEAS:BATC:IM? "MyParam",2GHz,2.005GHz
>
0.0,-72.130,0.0,-72.130,-1.270,-73.400,-0.570,-72.700,-0
.780,-72.910,-1.030,-73.160,-999.0,-999.0,-999.0,-999.0
