Table 2.17-11 Parameter List Settings (IM Measurement – SG Settings)
Parameter Attribute Name Setting Attribute Value Setting
Package Name
“Package Name”
Describes the Package
name to use.
Pattern Name
“Pattern Name”
Describes the Pattern name
to use.
Modulation
“Modulation”
“
On
”: On
“Off”: Off
External Trigger On/Off
“Trigger”
“
On
”: On
“Off”: Off
External Trigger Source
“Trigger Source”
“
Ext Trigger
”: External
“
Application Sync Trigger
”:
Application Sync
“
Baseband I/F
”: BBIF
External Trigger Mode
“Trigger Mode”
“
Start Trigger
”: Start Trigger
“
Frame Trigger
”:
Frame Trigger
External Trigger Edge
“Trigger Edge”
“
0
”: Fall
“
1
”: Rise
SA Trigger Out
“SA Trigger Out”
“
Marker1
”: Marker 1
“
Marker2
”: Marker 2
“
Marker3
”: Marker 3
“
Pattern Sync
”: Pattern Sync
Marker1 Polarity
“Marker1 Polarity”
“
1
”: Positive
“
0
”: Negative
Marker1 Edit
“Marker1 Edit”
“
ON
”: On
“
OFF
”: Off
“
SYNC
”: Pattern Sync
Frequency
“Frequency”
Describes in 0.01 Hz units.
RF Level
“RF Level”
Describes in dBm units.
Level Offset On/Off
“Offset”
“
On
”: On
“
Off
”: Off
Level Offset
“Offset Value”
Describes in dB units.
SG Output
“SG Output”
“
On
”: On
“
Off
”: Off
Level Auto CAL
“Level Auto CAL”
“
On
”: On
“
Off
”: Off
