Table 107: Parameter for test-name configuration (continued)
DescriptionParameters
TPID to be used in the outer VLAN tag.
Supported values are 0x8100, 0x88a8, 0x9100, 0x9200.
NOTE: This parameter is not supported on ACX5048 and ACX5096 routers.
outer-tag-protocol-id
CFI bit used in the outer VLAN tag.
NOTE: This parameter is not supported on ACX5048 and ACX5096 routers.
ovlan-cfi
Configure the outer VLAN ID for the test frames.
Range: 0 through 4094
This parameter is valid only for family ccc mode.
ovlan-id
Configure the priority value for the IEEE 802.1p bit in the outer VLAN tag.
Range: 0 through 7
NOTE: This parameter is not supported on ACX5048 and ACX5096 routers.
ovlan-priority
Specify the packet loss priority (PLP) value.
If a value is not configured, then the default value of low is used.
NOTE: This parameter is not supported on ACX5048 and ACX5096 routers.
packet-loss-priority
Specify the EtherType ID to be used for reflection of test frames. This parameter is valid only in
mode reflect. If not specified, then all EtherTypes are reflected.
Range: 1 through 65,535.
NOTE: This parameter is not supported on ACX5048 and ACX5096 routers.
reflect-etype
Specify the reflection mode (mac-rewrite | mac-swap | no-mac-swap).
•
mac-rewrite—MAC values specified in source-mac-address and destination-mac-address would
be used.
•
mac-swap—Swaps the source-mac-adddress and destination-mac-address in the test frame.
This is the default behavior.
•
no-mac-swap—Does not swap MAC addresses. Test frames are returned back as-is.
reflect-mode
Port used to configure reflector functionality for RFC 2544 test. The range of ports that can be
used based on the front panel port number are:
•
On ACX5048 [16 through 53]
•
On ACX5096 [64 through 95, 100 through 103].
reflector-port
Specify the service type (E-LINE, or E-LAN)service-type
Copyright © 2017, Juniper Networks, Inc.1344
ACX Series Universal Access Router Configuration Guide
