user@host# set test-profile throughput
19. Specify the logical interface, ge-0/0/0.1, on which the RFC 2544-based
benchmarking test is run.
[edit services rpm rfc2544-benchmarking tests test-name test1]
user@host# set test-interface ge-0/0/0.1
20. Specify the test mode for the packets that are sent during the benchmarking test
as initiation and termination.
[edit services rpm rfc2544-benchmarking tests test-name test1]
user@host# set mode initiate-and-terminate
21. Configure the address type family, inet, for the benchmarking test.
[edit services rpm rfc2544-benchmarking tests test-name test1]
user@host# set family inet
22. Configure the destination IPv4 address for the test packets.
[edit services rpm rfc2544-benchmarking tests test-name test1]
user@host# set dest-address 200.0.0.2
23. Specify the UDP port of the destination to be used in the UDP header for the
generated frames as 4001.
[edit services rpm rfc2544-benchmarking tests test-name test1]
user@host# set udp-port 4001
24. Start the benchmarking test on the initiator.
user@host> test services rpm rfc2544-benchmarking test test1 start
After the test is successfully completed, it is automatically stopped at the initiator.
Configuring Benchmarking Test Parameters on Router B
Step-by-Step
Procedure
The following example requires you to navigate various levels in the configuration
hierarchy. For information about navigating the CLI, see Using the CLI Editor in Configuration
Mode in the CLI User Guide.
To configure the test parameters on Router B:
1. In configuration mode, go to the [edit interfaces] hierarchy level:
[edit]
user@host# edit interfaces
2. Configure the interface on which the test must be run.
[edit interfaces]
1363Copyright © 2017, Juniper Networks, Inc.
Chapter 37: Configuring RFC 2544-Based Benchmarking Tests
