Table 150: show interfaces Gigabit Ethernet Output Fields (continued)
Level of OutputField DescriptionField Name
detail extensiveUnique number for use by Juniper Networks technical support only.Generation
For Gigabit Ethernet IQ PICs, traffic and MAC statistics output varies. Table 151 on page 2614
describes the traffic and MAC statistics for two sample interfaces, each of which is sending
traffic in packets of 500 bytes (including 478 bytes for the Layer 3 packet, 18 bytes for
the Layer 2 VLAN traffic header, and 4 bytes for cyclic redundancy check [CRC]
information). In Table 151 on page 2614, the ge-0/3/0 interface is the inbound physical
interface, and the ge-0/0/0 interface is the outbound physical interface. On both
interfaces, traffic is carried on logical unit .50 (VLAN 50).
Table 151: Gigabit Ethernet IQ PIC Traffic and MAC Statistics by Interface Type
CommentsByte and Octet Counts IncludeSample CommandInterface Type
The additional 4 bytes are
for the CRC.
Traffic statistics:
Input bytes: 496 bytes per packet, representing
the Layer 2 packet
MAC statistics:
Received octets: 500 bytes per packet,
representing the Layer 2 packet + 4 bytes
show interfaces
ge-0/3/0 extensive
Inbound physical
interface
Traffic statistics:
Input bytes: 478 bytes per packet, representing
the Layer 3 packet
show interfaces
ge-0/3/0.50 extensive
Inbound logical
interface
For input bytes, the
additional 12 bytes
includes 6 bytes for the
destination MAC address
+ 4 bytes for VLAN + 2
bytes for the Ethernet
type.
Traffic statistics:
Input bytes: 490 bytes per packet, representing
the Layer 3 packet + 12 bytes
MAC statistics:
Received octets: 478 bytes per packet,
representing the Layer 3 packet
show interfaces
ge-0/0/0 extensive
Outbound physical
interface
Traffic statistics:
Input bytes: 478 bytes per packet, representing
the Layer 3 packet
show interfaces
ge-0/0/0.50 extensive
Outbound logical
interface
Sample Output
show interfaces extensive (10-Gigabit Ethernet, LAN PHY Mode, IQ2)
user@host> show interfaces xe-5/0/0 extensive
Physical interface: xe-5/0/0, Enabled, Physical link is Up
Interface index: 177, SNMP ifIndex: 99, Generation: 178
Copyright © 2017, Juniper Networks, Inc.2614
