Table 205: show protection-group ethernet-ring statistics Output
Fields (continued)
Field DescriptionField Name
Number of times a manual switch event has occurred anywhere
else on the ring. This field is applicable only to MX Series routers.
Remote MS event received
Table 206 on page 2929 lists the output fields for the show protection-group ethernet-ring
statistics command when the detail option is used. These fields are valid only for MX
Series routers.
Table 206: show protection-group ethernet-ring statistics detail Output
Fields (for MX Series Routers)
Field DescriptionField Name
Number of times forwarding database (FDB) flush has happened
for the ring instance.
Total number of FDB flush
Number of times FDB flush has happened because of flush-logic
based on node ID and Blocked Port Reference (BPR).
Flush-logic triggered flush
Number of valid RAPS PDU messages received. This counter counts
only RAPS messages generated by other devices on the ring.
Remote RAPS PDU
received
Number of RAPS messages dropped by the device because the guard
timer is running.
Remote RAPS dropped due
to guard-timer
Number of RAPS messages dropped by the device because the
messages are invalid.
Invalid remote RAPS PDU
dropped
Number of RAPS messages dropped because of any other reason.
For example, messages dropped because of unsupported
functionality.
RAPS dropped due to
miscellaneous errors
Number of self-generated RAPS messages received and dropped.Local received RAPS PDU
dropped
Sample Output
show protection-group ethernet-ring statistics (EX Series Switch)
user@switch> show protection-group ethernet-ring statistics
Ring Name Local SF Remote SF NR Event NR-RB Event
erp1 2 1 2 3
show protection-group ethernet-ring statistics (MX Series Router)
user@host> show protection-group ethernet-ring statistics
Ethernet Ring statistics for PG Pg-1
RAPS event sent : 1
RAPS event received : 1152
Local SF happened: : 0
2929Copyright © 2017, Juniper Networks, Inc.
Chapter 42: Operational Commands
