3.9 Sweep/Trigger/Gate Settings
3-21
Native Device Message List
3
Native Device Message List
3
Table 3.9-1 Sweep/trigger/gate setting messages (Cont’d)
Function Command
Query Response Remarks
Gate Slope
GATESLOP edge GATESLOP? edge
edge :
= RISE | FALL
Gate Delay
GDL time
GDL?
time
Gate Length
GLN time GLN? time
Gate View
SWE:EGAT:VIEW
switch_com
SWE:EGAT:VIEW? switch_res
switch_com :
= ON | OFF | 1 | 0
switch_res :
= 1 | 0
Gate View Sweep Time
SWE:EGAT:TIME time SWE:EGAT:TIME? time
Gate View Resolution Bandwidth
Auto/Manual
SWE:EGAT:VIEW:BAND:A
UTO switch_com
SWE:EGAT:VIEW:BAND:A
UTO?
switch_res
switch_com :
= ON | OFF | 1 | 0
switch_res :
= 1 | 0
Gate View Resolution Bandwidth
SWE:EGAT:VIEW:BAND
freq
SWE:EGAT:VIEW:BAND? freq
Gate View Video Bandwidth
Auto/Manual
SWE:EGAT:VIEW:BAND:V
ID:AUTO switch_com
SWE:EGAT:VIEW:BAND:V
ID:AUTO?
switch_res
switch_com :
= ON | OFF | 1 | 0
switch_res :
= 1 | 0
Gate View Video Bandwidth
SWE:EGAT:VIEW:BAND:V
ID freq
SWE:EGAT:VIEW:BAND:V
ID?
freq
