Native Device Message List
3-22
Table 3.9-1 Sweep/trigger/gate setting messages (Cont’d)
Function Command
Query Response Remarks
Gate View Detection Mode
SWE:EGAT:VIEW:DET det
SWE:EGAT:VIEW:DET? det
det:
= NORM | POS | NEG | SAMP | RMS
Gate View Trace Point
SWE:EGAT:VIEW:POIN
integer
SWE:EGAT:VIEW:POIN? integer
Gate View Frequency Mode
SWE:EGAT:VIEW:FREQ:A
UTO switch_com
SWE:EGAT:VIEW:FREQ:A
UTO?
switch_res
switch_com:
= ON | OFF | 1 | 0
switch_res:
= 1 | 0
Gate View Frequency
SWE:EGAT:VIEW:FREQ
freq
SWE:EGAT:VIEW:FREQ? freq
Gate Hold
SWE:EGAT:HOLD time SWE:EGAT:HOLD? time
Gate Hold On/Off
SWE:EGAT:HOLD:STAT
switch
SWE:EGAT:HOLDSTAT? switch
switch:
Gate Hold On/Off
= ON | OFF | 1 | 0
Trigger Hold
TRIG:HOLD time TRIG:HOLD? time
Trigger Hold On/Off
TRIG:HOLD:STAT switch
TRIG:HOLD:STAT? switch
switch:
Trigger Hold On/Off
= ON | OFF | 1 | 0
Frame Trigger Period
TRIG:FRAM:PER time TRIG:FRAM:PER? time
Frame Sync Source
TRIG:FRAM:SYNC sync TRIG:FRAM:SYNC? sync
sync: Synchronized
signal
source
= EXT | IMM | WIF
Frame Sync Offset
TRIG:FRAM:OFFS time TRIG:FRAM:OFFS? time
