Chapter
３
Native Device Message List
3-44
Table 3.10.6-1 Spectrum Emission Mask measurement function setting messages (Cont’d)
Function Command Query Response Remarks
Spectrum Emission Mask Fetch
--- FETC:SEM? n
total_judge,ref_power,
abs_lower_offset_1,abs_upper_offs
et_1,
margin_lower_offset_1,margin_uppe
r_offset_1,
freq_lower_offset_1,freq_upper_of
fset_1,
lower_offset_1,upper_offset_1,
......
abs_lower_offset_12,abs_upper_off
set_12,
margin_lower_offset_12,margin_upp
er_offset_12,freq_lower_offset_12
,freq_upper_offset_12,lower_offse
t_12,upper_offset_12
(n=13)
When the result mode is “B”.
ref_power :
Reference absolute
power
abs_lower_offset_m :
Peak value of absolute power of
lower Offset-m
abs_upper_offset_m :
Peak value of absolute power of
upper Offset-m
rel_lower_offset_m :
Peak value of relative power of
lower Offset-m
rel_upper_offset_m :
Peak value of relative power of
upper Offset-m
margin_lower_offset_m :
Minimum value of margin of lower
Offset-m
margin_upper_offset_m :
Minimum value of margin of upper
Offset-m
freq_lower_offset_m :
Frequency of peak level of lower
Offset-m
freq_upper_offset_m :
Frequency of peak level of upper
Offset-m
lower_offset_m :
Judgment result of lower Offset-m
upper_offset_m :
Judgment result of upper Offset-m
Spectrum Emission Mask Read
--- READ:SEM? n
Spectrum Emission Mask
Measure
--- MEAS:SEM? n
