3.10 Measure Function Settings
3-43
Native Device Message List
3
Native Device Message List
3
Table 3.10.6-1 Spectrum Emission Mask measurement function setting messages (Cont’d)
Function Command Query Response Remarks
Spectrum Emission Mask Fetch
--- FETC:SEM? n
-999.0,-999.0,
lower_offset_1,upper_offset_1, ..
..
lower_offset_12,upper_offset_12
(n=7 or 8)
-999.0,-999.0,
abs_lower_offset_1,abs_upper_offs
et_1, ....
abs_lower_offset_12,abs_upper_off
set_12
(n=10)
-999.0,-999.0,
rel_lower_offset_1,rel_upper_offs
et_1, ....
rel_lower_offset_12,rel_upper_off
set_12
(n=11)
When the result mode is “B”.
ref_power
:Reference absolute
power
abs_lower_offset_m
:
Peak value of absolute power of
lower Offset-m
abs_upper_offset_m
:
Peak value of absolute power of
upper Offset-m
rel_lower_offset_m
:
Peak value of relative power of
lower Offset-m
rel_upper_offset_m
:
Peak value of relative power of
upper Offset-m
margin_lower_offset_m
:
Minimum value of margin of lower
Offset-m
margin_upper_offset_m
:
Minimum value of margin of upper
Offset-m
freq_lower_offset_m
:
Frequency of peak level of lower
Offset-m
freq_upper_offset_m
:
Frequency of peak level of upper
Offset-n
lower_offset_m
:
Judgment result of lower Offset-m
upper_offset_m
:
Judgment result of upper Offset-m
Spectrum Emission Mask Read
--- READ:SEM? n
Spectrum Emission Mask
Measure
--- MEAS:SEM? n
