3.10 Measure Function Settings
3-51
Native Device Message List
3
Native Device Message List
3
Table 3.10.7-1 Spurious Emission Measurement function setting messages (Cont’d)
Function Command Query Response Remarks
Spurious Emission Fetch
--- FETC:SPUR? n
When Result Mode is set to A:
(When Spurious Emission Result Type
is Worst)
judge,spur_1,range_1,peak_1,margi
n_1,limit_1,judge_1,spur_2,range_
2freq_2,peak_2,margin_2,limit_2,j
udge_2
……
spur_20,range_20,freq_20,peak_20,
margin_20,limit_20,judge_20
(n=1 or when omitted.)
(When Spurious Emission Result Type is
set to Peak:)
judge,spur_1,range_1,freq_1,peak_
1,margin_1,limit_1,judge_1,spur_2
,range_2,freq_2,peak_2,margin_2,l
imit_2,judge_2
……
spur_n,freq_n,peak_n,margin_n,lim
it_n,judge_n
(n=1 or when omitted.)
When
Result Mode is set to B:
spur_1,range_1,freq_1,peak_1,limi
t_1,judge_1,spur_2,range_2,freq_2
,peak_2,limit_2,judge_2
……
spur_n,range_n,freq_n,peak_n,limi
t_n,judge_n
(n=1 or when omitted.)
tracedata_1,tracedata_2
……
traceda
ta_m
(n=2 to 21)
number
(n=22)
tracedata_1,tracedata_2
……
traceda
ta_m
(n=23 to 42)
range_n: Segment
number of the detected
spurious
spur_n: Spurious
number
number:Number of the
detected spurious
freq_n:Frequency of
Spurious
peak_n:Absolute power
of spurious
margin_n:Relative
power from the limit
line of Spurious
limit_n:Power value
of the limit line of
Spurious
judge_n : Limit line
judges the detected
spurious as Pass or
Fail.
tracedata_m:Trace
data of the m point.
judge: Pass/Fail
judgment for the whole
segment
Spurious Emission Read
--- READ:SPUR? n
Spurious Emission Measure
--- MEAS:SPUR? n
