2.17 Configuring Batch Measurement Settings
2-873
2
SCPI Device Message Details
Table 2.17-6 Parameter List Example (SEM Measurement) (Cont’d)
<Attribute Name="SEM Offset1 ABS1 Start Level" Value="-550" />
<Attribute Name="SEM Offset1 ABS1 Stop Level" Value="-1250" />
<Attribute Name="SEM Offset1 Fail Logic" Value="ABS1" />
<Attribute Name="SEM Offset2 Switch" Value="On" />
<Attribute Name="SEM Offset2 Start Freq" Value="7550000" />
<Attribute Name="SEM Offset2 Stop Freq" Value="12550000" />
<Attribute Name="SEM Offset2 Reference Level Switch" Value="Auto" />
<Attribute Name="SEM Offset2 RBW Value" Value="100kHz" />
<Attribute Name="SEM Offset2 SweepTime Switch" Value="Auto" />
<Attribute Name="SEM Offset2 Auto Sweep Time Select" Value="Normal" />
<Attribute Name="SEM Offset2 Detection" Value="RMS" />
<Attribute Name="SEM Offset2 TracePoint" Value="1001" />
<Attribute Name="SEM Offset2 Integrate BW Switch" Value="Auto" />
<Attribute Name="SEM Offset2 ABS1 Start Level" Value="-1250" />
<Attribute Name="SEM Offset2 ABS1 Stop Level" Value="-1250" />
<Attribute Name="SEM Offset2 Fail Logic" Value="ABS1" />
<Attribute Name="SEM Offset3 Switch" Value="On" />
<Attribute Name="SEM Offset3 Start Freq" Value="12550000" />
<Attribute Name="SEM Offset3 Stop Freq" Value="47500000" />
<Attribute Name="SEM Offset3 Reference Level Switch" Value="Auto" />
<Attribute Name="SEM Offset3 RBW Value" Value="100kHz" />
<Attribute Name="SEM Offset3 SweepTime Switch" Value="Auto" />
<Attribute Name="SEM Offset3 Auto Sweep Time Select" Value="Normal" />
<Attribute Name="SEM Offset3 Detection" Value="RMS" />
<Attribute Name="SEM Offset3 TracePoint" Value="1001" />
<Attribute Name="SEM Offset3 Integrate BW Switch" Value="Auto" />
<Attribute Name="SEM Offset3 ABS1 Start Level" Value="-1300" />
<Attribute Name="SEM Offset3 ABS1 Stop Level" Value="-1300" />
<Attribute Name="SEM Offset3 Fail Logic" Value="ABS1" />
<Attribute Name="SEM Offset4 Switch" Value="Off" />
<Attribute Name="SEM Offset4 Fail Logic" Value="Off" />
<Attribute Name="SEM Offset5 Switch" Value="Off" />
<Attribute Name="SEM Offset5 Fail Logic" Value="Off" />
<Attribute Name="SEM Offset6 Switch" Value="Off" />
<Attribute Name="SEM Offset6 Fail Logic" Value="Off" />
</CommonParams>
</SemParams>
</Params>
</SignalAnalyzerProject>
