Chapter 2 SCPI Device Message Detail
2-874
Describe the setting parameters in the part enclosed between the
CommonParams elements. The description method consists in describing
the parameter name to be set in the Name attribute in the Attribute
element, and the setting value in Value. The parts in bold characters in
Table 2.17-6 are an actual setting example. Describe all other parts the
same as in Table 2.17-6.
Since the settings are done in sequence from the top, be careful about the
description order when setting parameters that have relationships of
dependence. Also, if a value that is either out of the setting range or that
cannot be set has been input, that setting is ignored.
Table 2.17-7 Parameter List Settings (SEM Measurement)
Parameter Attribute Name Setting Attribute Value Setting
Center Frequency
“Center Freq.”
Value is described
in Hz units.
Spurious Mode
“Frequency Band Spurious
Mode”
Spurious
Reference Level
“Reference Level”
Value is described
in dBm units.
Reference Level Offset
“Reference Level Offset”
Off
Reference Level Offset Value
“Reference Level Offset
Value is described
in 0.01 dB units.
Storage Mode
“Storage Mode A”
“
Lin
Average
”: Lin Average
“
Average
”: Average
“
Max
Hold
”: Max Hold
“
Min
Hold
”: Min Hold
Off
Describes the storage count.
