C613-50100-01 REV C Command Reference for x930 Series 1755
AlliedWare Plus™ Operating System - Version 5.4.6-1.x
PIM-SM COMMANDS
SHOW
IP PIM SPARSE-MODE MROUTE
show ip pim sparse-mode mroute
Overview This command displays the IP multicast routing table, or the IP multicast routing
table based on the specified address or addresses.
Two group addresses cannot be used simultaneously; two source addresses
cannot be used simultaneously.
Note that when a feature license is enabled, the output for the show ip pim
sparse-mode mroute command will only show 32 interfaces because of the
terminal display width limit. Use the show ip pim sparse-mode mroute detail
command to display detailed entries of the IP multicast routing table.
For information on filtering and saving command output, see the “Getting Started
with AlliedWare Plus” Feature Overview and Configuration Guide.
Syntax
show ip pim sparse-mode mroute
[<group-address|<source-address>]
show ip pim sparse-mode mroute [<source-address>
<group-address>]
show ip pim sparse-mode mroute [<group-address>
<source-address>]
Mode User Exec and Privileged Exec
Usage Note that when a feature license is enabled, the output for show ip pim
sparse-mode mroute command will only show 32 interfaces because of the
terminal display width limit. Use the show ip pim sparse-mode mroute detail
command to display detailed entries of the IP multicast routing table.
Examples
awplus# show ip pim sparse-mode mroute
awplus# show ip pim sparse-mode mroute 40.40.40.11
awplus# show ip pim sparse-mode mroute 235.0.0.1
awplus# show ip pim sparse-mode mroute 235.0.0.1 40.40.40.11
Parameter Description
<group-address> Group IP address, entered in the form A.B.C.D. Based on the
group and source address, the output is the selected route if
present in the multicast route tree.
<source-address> Source IP address, entered in the form A.B.C.D. Based on the
source and group address, the output is the selected route if
present in the multicast route tree.
