C613-50100-01 REV C Command Reference for x930 Series 327
AlliedWare Plus™ Operating System - Version 5.4.6-1.x
PLUGGABLES AND CABLING COMMANDS
SHOW
TEST CABLE-DIAGNOSTICS TDR
show test cable-diagnostics tdr
Overview Use this command to display the results of the last cable-diagnostics test that was
run using the TDR (Time Domain Reflectometer) on a fixed copper cable port.
The displayed status of the cable can be either:
•OK
•Open
• Short (within-pair)
• Short (across-pair)
• Error
Syntax
show test cable-diagnostics tdr
Mode Privileged Exec
Examples To show the results of a cable-diagnostics test use the following command:
awplus# show test cable-diagnostics tdr
Output Figure 8-9: Example output from the show test cable-diagnostics tdr
command
Related
Commands
clear test cable-diagnostics tdr
test cable-diagnostics tdr interface
Port Pair Length Status 
------------------------------------------------- 
1.0.1 A - OK 
B - OK 
C - OK 
D - OK
