C613-50100-01 REV C Command Reference for x930 Series 669
AlliedWare Plus™ Operating System - Version 5.4.6-1.x
POWER OVER ETHERNET COMMANDS
POWER
-INLINE MAX
power-inline max
Overview Note that the value set by this command will be the figure the switch will use when
apportioning the power budget for its ports. For example, if 15.4 W is assigned to
a port whose PD only consumes 5 W, the switch will reserve the full 15.4 W for this
port when determining its total power PoE power requirement.
The no variant of this command sets the maximum power supplied to a PoE port
to the default, which is set to the maximum power limit for the class of the
connected Powered Device (PD).
Syntax
power-inline max <4000-30000>
no power-inline max
Default The switch supplies the maximum power limit for the class of the PD connected to
the port by default.
NOTE: See the PoE Feature Overview and Configuration Guide for further information
about power classes.
Mode Interface Configuration for one or more ports. If you specify a range or list of ports,
they must all be PoE capable ports.
Usage In a stack of x610 Series switches this command is supported on all PoE capable
ports.
If you select a range of PoE ports in Interface Configuration mode before issuing
this command, then each port in the range selected will have the same maximum
power value configured. If the PoE port attempts to draw more than the maximum
power, this is logged and all power is removed. Note that the value entered is
rounded up to the next value supported by the hardware.
See the actual value used, as shown after command entry, in the sample console
output below:
Parameter Description
<4000-30000> The maximum power supplied to a PoE port in milliwatts
(mW).
awplus#configure terminal
awplus(config)#interface port1.0.1
awplus(config-if)#power-line max 5300
% The maximum power has been rounded to 5450mW in hardware.
