C613-50100-01 REV C Command Reference for x930 Series 551
AlliedWare Plus™ Operating System - Version 5.4.6-1.x
VLAN COMMANDS
VLAN
CLASSIFIER RULE PROTO
vlan classifier rule proto
Overview Use this command to create a protocol type-based VLAN classifier rule, and map it
to a specific VLAN. See the published IANA EtherType IEEE 802 numbers here:
www.iana.org/assignments/ieee-802-numbers/ieee-802-numbers.txt.
Instead of a protocol name the decimal value of the protocol's EtherType can be
entered. The EtherType field is a two-octet field in an Ethernet frame. It is used to
show which protocol is encapsulated in the payload of the Ethernet frame. Note
that EtherTypes in the IANA 802 numbers are given as hexadecimal values.
The no variant of this command removes a previously set rule.
Syntax
vlan classifier rule <1-256> proto <protocol> encap
{ethv2|nosnapllc|snapllc} vlan <1-4094>
no vlan classifier rule <1-256>
Parameter Description
<1-256> VLAN Classifier identifier
proto Protocol type
<protocol> Specify a protocol either by its decimal number (0-65535) or by one
of the following protocol names:
[arp|2054] Address Resolution
protocol
[atalkaarp|33011] Appletalk AARP protocol
[atalkddp|32923] Appletalk DDP protocol
[atmmulti|34892] MultiProtocol Over ATM
protocol
[atmtransport|34948] Frame-based ATM
Transport protocol
[dec|24576] DEC Assigned protocol
[deccustom|24582] DEC Customer use
protocol
[decdiagnostics|24581] DEC Systems Comms
Arch protocol
[decdnadumpload|24577] DEC DNA Dump/Load
protocol
[decdnaremoteconsole|24578] DEC DNA Remote
Console protocol
[decdnarouting|24579] DEC DNA Routing
protocol
[declat|24580] DEC LAT protocol
