C613-50100-01 REV C Command Reference for x930 Series 2040
AlliedWare Plus™ Operating System - Version 5.4.6-1.x
QOS COMMANDS
SHOW
PLATFORM CLASSIFIER STATISTICS UTILIZATION BRIEF
show platform classifier statistics utilization
brief
Overview This command displays the number of used entries available for various platform
functions, and the percentage that number of entries represents of the total
available.
Syntax
show platform classifier statistics utilization brief
Mode Privileged Exec
Example To display the platform classifier utilization statistics, use the following command:
awplus# show platform classifier statistics utilization brief
Output Figure 41-10: Output from the show platform classifier statistics utilization
brief command
Note that QoS entries and ACLs share the same area of dedicated ASIC memory, so
increasing the number of ACLs reduces the number of QoS class-maps and
policy-maps available. ASIC memory is allocated in “groups” of 256 entries. The
switch automatically allocates the correct number of groups to ACLs and QoS as
you create more ACLs or QoS class-maps and policy-maps. The output example
above is for a switch where:
• 758 entries are allocated to ACLs, of which 702 entries are used, and
• 1024 entries are allocated to QoS, of which 850 entries are used, and
• 256 entries are unallocated (2038 - 1024 - 758 = 256)
Related
Commands
show platform
awplus#show platform classifier statistics utilization brief
...[Instance 4]
Capacity: 2038
Number of Entries:
Policy Type Group ID Used / Allocated
----------------------------------------------
ACL 1476395009 702 / 758 ( 92%)
DoS Inactive 0 / 0 ( 0%)
VLAN Counter
Group-Octet Inactive 0 / 0 ( 0%)
Group-Packet Inactive 0 / 0 ( 0%)
QoS 850 / 1024 ( 83%)
Group-0 1 250 / 256 ( 97%)
Group-1 2 250 / 256 ( 97%)
Group-2 3 250 / 256 ( 97%)
Group-3 4 100 / 256 ( 39%)
