C613-50100-01 REV C Command Reference for x930 Series 1676
AlliedWare Plus™ Operating System - Version 5.4.6-1.x
MLD AND MLD SNOOPING COMMANDS
SHOW
IPV6 MLD GROUPS
show ipv6 mld groups
Overview Use this command to display the multicast groups that have receivers directly
connected to the router and learned through MLD.
For information on filtering and saving command output, see the “Getting Started
with AlliedWare Plus” Feature Overview and Configuration Guide.
Syntax
show ipv6 mld groups [<ipv6-address>|<interface>] [detail]
Mode User Exec and Privileged Exec
Examples The following command displays local-membership information for all interfaces:
awplus# show ipv6 mld groups
Output Figure 32-2: Example output for show ipv6 mld groups
The following command displays local-membership information for all interfaces:
awplus# show ipv6 mld groups detail
Output Figure 32-3: Example output for show ipv6 mld groups detail
Parameter Description
<ipv6-address> Optional. Specify Address of the multicast group in format
X:X::X:X.
<interface> Optional. Specify the Interface name for which to display local
information.
awplus#show ipv6 mld groups
MLD Connected Group Membership
Group Address Interface Uptime Expires
Last Reporter
ff08::1 vlan10 (port1.0.1) 00:07:27 00:03:10
fe80::200:1ff:fe20:b5ac
MLD Connected Group Membership Details for port1.0.1
Interface: port1.0.1
Group: ff08::1
Uptime: 00:00:13
Group mode: Include ()
Last reporter: fe80::eecd:6dff:fe6b:4783
Group source list: (R - Remote, M - SSM Mapping, S - Static )
Source Address Uptime v2 Exp Fwd Flags
2001:db8::1 00:00:13 00:04:07 Yes R
2002:db8::3 00:00:13 00:04:07 Yes R
