C613-50100-01 REV C Command Reference for x930 Series 1905
AlliedWare Plus™ Operating System - Version 5.4.6-1.x
IPV4 SOFTWARE ACCESS CONTROL LIST (ACL) COMMANDS
ACCESS
-LIST (EXTENDED NUMBERED)
access-list (extended numbered)
Overview This command configures an extended numbered access-list that permits or
denies packets from specific source and destination IP addresses. You can either
create an extended numbered ACL together with an ACL filter entry in the Global
Configuration mode, or you can use the IPv4 Extended ACL Configuration mode
for sequenced ACL filter entry after entering a list number.
The no variant of this command removes a specified extended named access-list.
Syntax
[list-number]
access-list {<100-199>|<2000-2699>}
no access-list {<100-199>|<2000-2699>}
Syntax [deny|
permit]
access-list {<100-199>|<2000-2699>} {deny|permit} ip <source>
<destination>
no access-list {<100-199>|<2000-2699>}{deny|permit} ip <source>
<destination>
Parameter Description
<100-199> IP extended access-list.
<2000-2699> IP extended access-list (expanded range).
Parameter Description
<100-199> IP extended access-list.
<2000-2699> IP extended access-list (expanded range).
deny Access-list rejects packets that match the source and destination
filtering specified with this command.
permit Access-list permits packets that match the source and destination
filtering specified with this command.
<source> The source address of the packets. You can specify a single host, a
subnet, or all sources. The following are the valid formats for
specifying the source:
any Matches any source IP address.
host<ip-addr> Matches a single source host with the IP
address given by <ip-addr> in dotted
decimal notation.
<ip-addr>
<reverse-mask>
An IPv4 address, followed by a reverse
mask in dotted decimal format. For
example, entering 192.168.1.1
0.0.0.255 is the same as entering
192.168.1.1/24. This matches any
source IP address within the specified
subnet.
