C613-50100-01 REV C Command Reference for x930 Series 2673
AlliedWare Plus™ Operating System - Version 5.4.6-1.x
ALLIED TELESIS MANAGEMENT FRAMEWORK™ (AMF) COMMANDS
SHOW
ATMF VIRTUAL-LINKS
show atmf virtual-links
Overview This command displays a summary of all virtual links (L2TP tunnels) currently in the
running configuration.
Syntax
show atmf virtual-links [macaddress]
Mode Privileged Exec
Example 1 To display AMF virtual links, use the command:
node_1# show atmf virtual-links
In the above example, a centrally located switch has the IP address space
192.0.2.x/24. It has two VLANs assigned the subnets 192.0.2.33 and 192.0.2.65
using the prefix /27. Each subnet connects to a virtual link. The first link has the IP
address 192.168.1.1 and has a Local ID of 1. The second has the IP address
192.168.2.1 and has the Local ID of 2.
Example 2 To display AMF virtual links MAC address information, use the command:
node_1# show atmf virtual-links macaddr
Parameter Description
show Show running system information
atmf The Allied Telesis Management Framework (AMF)
virtual-links Virtual AMF links information.
macaddr Virtual AMF links Mac Address.
Table 60: Sample output from the show atmf virtual-links command.
ATMF Link Remote Information:
Local Local Local Remote Remote Retries State
Port Ip Id Ip Id
------------------------------------------------------------------------
vlink1 192.0.2.33 1 192.168.1.1 2 0 Down
vlink2 192.0.2.65 2 192.168.2.0 3 0 Up
