C613-50100-01 REV C Command Reference for x930 Series 2917
AlliedWare Plus™ Operating System - Version 5.4.6-1.x
LLDP COMMANDS
SHOW
LLDP NEIGHBORS
Related
Commands
show lldp neighbors detail
Table 60: Parameters in the output of the show lldp neighbors command
Parameter Description
Local Port Local port on which the neighbor information was
received.
Neighbor Chassis ID Chassis ID that uniquely identifies the neighbor.
Neighbor Port Name Port ID of the neighbor.
Neighbor Sys Name System name of the LLDP neighbor.
Neighbor Capability Capabilities that are supported and enabled on the
neighbor.
System Capability System Capabilities of the LLDP neighbor.
MED Device Type LLDP-MED Device class (Class I, II, III or Network
Connectivity)
MED Power Source LLDP-MED Power Source
