C613-50100-01 REV C Command Reference for x930 Series 2030

AlliedWare Plus™ Operating System - Version 5.4.6-1.x

QOS COMMANDS

SHOW

MLS QOS

show mls qos

Overview Use this command to display whether QoS is enabled or disabled on the switch.

Syntax

show mls qos

Mode User Exec and Privileged Exec

Example To display whether QoS is enabled or disabled, use the command:

awplus# show mls qos

Output Figure 41-3: Example output from the show mls qos command

Commands

mls qos enable

awplus#show mls qos

Enable
