C613-50100-01 REV C Command Reference for x930 Series 431
AlliedWare Plus™ Operating System - Version 5.4.6-1.x
PORT MIRRORING AND REMOTE MIRRORING COMMANDS
SHOW
MIRROR INTERFACE
show mirror interface
Overview Use this command to display port mirroring configuration for a mirrored
(monitored) switch port.
Syntax
show mirror interface <port>
Mode User Exec, Privileged Exec and Interface Configuration
Example To display port mirroring configuration for the port1.0.4, use the following
commands:
awplus# configure terminal
awplus(config)# interface port1.0.4
awplus(config-if)# show mirror interface port1.0.4
Output Figure 12-2: Example output from the show mirror interface command
Parameter Description
<port> The monitored switch port to display information about.
Mirror Test Port Name: port1.0.3
Mirror option: Enabled
Mirror direction: both
Monitored Port Name: port1.0.4
