C613-50100-01 REV C Command Reference for x930 Series 1708

AlliedWare Plus™ Operating System - Version 5.4.6-1.x

MULTICAST COMMANDS

SHOW

IP RPF

show ip rpf

Overview Use this command to display Reverse Path Forwarding (RPF) information for the

specified IPv4 source address.

Syntax

show ip rpf <source-addr>

Mode User Exec and Privileged Exec

Example

awplus# show ip rpf 10.10.10.50

Parameter Description

<ipv4-source- addr> Source IPv4 address, in dotted decimal notation in the

format A.B.C.D.

Default Chapter3
