C613-50100-01 REV C Command Reference for x930 Series 451

AlliedWare Plus™ Operating System - Version 5.4.6-1.x

SWITCHING COMMANDS

CLEAR

PORT COUNTER

clear port counter

Overview Use this command to clear the packet counters of the port.

Syntax

clear port counter [<port>]

Mode Privileged Exec

Example To clear the packet counter for port1.0.1, use the command:

awplus# clear port counter port1.0.1

Commands

show platform port

Parameter Description

<port> The port number or range

Default Chapter3
