C613-50100-01 REV C Command Reference for x930 Series 2496
AlliedWare Plus™ Operating System - Version 5.4.6-1.x
VRRP COMMANDS
TRANSITION
-MODE
transition-mode
Overview Use this command to configure the IPv4 transition mode. Transition mode allows
you to upgrade from VRRPv2 to VRRPv3 and gives interoperability between
VRRPv2 and VRRPv3.
If transition-mode is set to true, then the IPv4 transition mode is enabled and
VRRPv2 and VRRPv3 advertisements are sent allowing VRRPv2 and VRRPv3
interoperability. Received VRRPv2 advertisement packets are accepted and
processed when transition-mode is true.
If transition-mode is set to false, then the IPv4 transition mode is disabled and only
VRRPv3 advertisements are sent. Received VRRPv2 advertisement packets are
dropped.
Note the advertisement-interval should not be configured to less than 1 second
when using transition-mode. VRRPv2 can only use advertisements in whole
second intervals.
Syntax
transition-mode {true|false}
Default The default is false.
Mode Router Configuration
Usage See the VRRP Feature Overview and Configuration Guide for more information:
• VRRPv3 IPv4 configuration details
• VRRPv3 IPv6 configuration details
• further information about configuring transition mode to upgrade from
VRRPv2 to VRRPv3
Examples The example below shows you how to configure IPv4 transition-mode as true for
VRRP VR ID 5 on vlan2:
awplus# configure terminal
awplus(config)# router vrrp 5 vlan2
awplus(config-router)# transition-mode true
Parameter Description
true Transition mode is enabled. This results in VRRPv2 and VRRPv3 IPv4
advertisements being sent. Transition mode is only available on
VRRPv3 for interoperability with VRRPv2 while upgrading to VRRPv3.
false Transition mode is disabled. This stops VRRPv2 IPv4 advertisements
being sent. Only VRRPv3 advertisements are sent when disabled.
Disable transition-mode after upgrading from VRRPv2 to VRRPv3.
