C613-50100-01 REV C Command Reference for x930 Series 1818
AlliedWare Plus™ Operating System - Version 5.4.6-1.x
PIM-SMV6 COMMANDS
SHOW
IPV6 PIM SPARSE-MODE NEIGHBOR
show ipv6 pim sparse-mode neighbor
Overview Use this command to show the PIM-SMv6 neighbor information.
For information on filtering and saving command output, see the “Getting Started
with AlliedWare Plus” Feature Overview and Configuration Guide.
Syntax
show ipv6 pim sparse-mode neighbor [<interface>]
[<IPv6-address>] [detail]
Mode User Exec and Privileged Exec
Examples
awplus# show ipv6 pim sparse-mode neighbor
awplus# show ipv6 pim sparse-mode neighbor vlan5 detail
Figure 35-9: Example output from the show ipv6 pim sparse-mode neighbor
command
Figure 35-10: Example output from the show ipv6 pim sparse-mode neighbor
interface detail command
Parameter Description
<interface> Interface name (e.g. vlan2). Show neighbors on an interface.
<IPv6-address> Show neighbors with a particular address on an interface. The
IPv6 address entered in the form X:X::X:X.
detail Show detailed information.
awplus#show ipv6 pim sparse-mode neighbor
Neighbor Address Interface Uptime/Expires DR
Pri/Mode
fe80::202:b3ff:fed4:69fe vlan2 05:33:52/00:01:41 1 /
fe80::20e:cff:fe01:facc vlan3 05:33:53/00:01:26 1 / DR
awplus#show ipv6 pim sparse-mode neighbor detail
Nbr fe80::211:11ff:fe44:4cd8 (vlan1), DR
Expires in 64 seconds, uptime 00:00:53
Holdtime: 70 secs, T-bit: off, Lan delay: 1, Override interval: 3
DR priority: 100, Gen ID: 1080091886,
Secondary addresses:
3ffe:10:10:10:3::180
