C613-50100-01 REV C Command Reference for x930 Series 916
AlliedWare Plus™ Operating System - Version 5.4.6-1.x
RIP COMMANDS
SHOW
IP RIP VRF DATABASE
show ip rip vrf database
Overview Use this command to display information about the RIP database that is associated
with a specific VRF instance.
Entering this command with the full option included, will display information
about the full RIP database (including sub-optimal routes) associated with a
specific VRF instance.
For information on filtering and saving command output, see the “Getting Started
with AlliedWare Plus” Feature Overview and Configuration Guide.
Syntax (VRF lite)
show ip rip {vrf <vrf-name>|global} database [full]
Mode User Exec and Privileged Exec
Example To display information about the RIP database associated with a VRF instance
blue, use the command:
awplus# show ip rip vrf blue database
Output Figure 24-3: Example output from the show ip rip vrf blue database command
Related
Commands
show ip rip
Parameter Description
vrf Specific VRF instance.
<vrf-name> The name of the VRF instance.
global The global routing and forwarding table.
full Specify the full RIP database including sub-optimal RIP routes.
Codes: R - RIP, Rc - RIP connected, Rs - RIP static
C - Connected, S - Static, O - OSPF, B - BGP
Network Next Hop Metric From If Time
Rc 192.168.30.0/24 1 vlan3
R 192.168.45.0/24 192.168.30.1 2 192.168.30.1 vlan3 02:46
